DATA CENTER LIQUID COOLING HOSE
DATA CENTER LIQUID COOLING HOSE specifications
Structure
Inner Tube: Black EPDM synthetic rubber Reinforcement: One or two layers of synthetic fiber braided reinforcement Outer Layer: Black weather resistant, wear-resistant, ozone resistant, V0 flame retardant EPDM synthetic rubber
Application
Suitable for air, water, water glycol, oil-water emulsion, antifreeze, phosphate ester hydraulic oil and other media fluids .
Working Temperature
-40℃~+120℃（-40℉~+248℉）
Service Support
Selection guidance and after-sales technical support - call 137 2136 0724
| SPECIFICATION | HOSE INNER DIAMETER （I.D）mm | HOSE OUTER DIAMETER （O.D）mm | MAXIMUM WORKING PRESSURE Max.W.P (MPa) | MINIMUM BURST PRESSURE Min.B.P (MPa) | MINIMUM BENDING RADIUS Min.B.R (mm) | REFERENCE WEIGHT W.T (kg/m) | ||
| inch | min | max | min | max | MPa | MPa | mm | kg/m |
| 1/4" | 6.1 | 7.2 | 11.6 | 12.6 | 1.38 | 5.5 | 24.5 | 0.13 |
| 5/16" | 7.7 | 8.3 | 14.5 | 15.5 | 1.38 | 5.5 | 31.5 | 0.18 |
| 3/8" | 9.5 | 10.3 | 15.4 | 16.4 | 1.38 | 5.5 | 37 | 0.19 |
| 1/2" | 12.5 | 13.3 | 19.7 | 20.7 | 1 | 1 | 69 | 0.25 |
| 5/8" | 15.8 | 16.6 | 22.5 | 23.7 | 1 | 1 | 88 | 0.30 |
| 3/4" | 18.8 | 19.6 | 26.4 | 27.6 | 1 | 1 | 113 | 0.35 |
| 1" | 25.2 | 26.2 | 33.6 | 34.8 | 1 | 1 | 143 | 0.52 |
| 1 1/4" | 31.8 | 32.8 | 43 | 44.6 | 1 | 1 | 195 | 0.70 |
