| 产品名称 | 公称内径 | 规格 | 内径 （ID）mm | 增强层外径 （W.D）mm | 外径 （OD）mm | 最大工作压力 W.P | 最小爆破压力 B.P | 最小弯曲半径 Min.B.R | 参考重量 W.T | |||
| mm | inch | min | max | min | max | min | max | Mpa | Mpa | mm | Kg/m | |
| R13-12-19 | 19 | 3/4“ | 18.6 | 19.8 | 28.2 | 29.8 | 31.0 | 33.2 | 35.0 | 140.0 | 240.0 | 1.36 |
| R13-16-25 | 25 | 1” | 25 | 26.4 | 34.9 | 36.4 | 37.6 | 39.8 | 35.0 | 140.0 | 300.0 | 2.12 |
| R13-20-31.5 | 32 | 1-1/4“ | 31.4 | 33.0 | 45.6 | 48.0 | 48.3 | 51.3 | 35.0 | 140.0 | 420.0 | 3.75 |
| R13-24-38 | 38 | 1-1/2” | 37.7 | 39.3 | 53.1 | 55.5 | 55.8 | 58.8 | 35.0 | 140.0 | 500.0 | 5.49 |
| R13-32-51 | 51 | 2“ | 50.4 | 52.0 | 66.9 | 69.3 | 69.3 | 72.7 | 35.0 | 140.0 | 640.0 | 7.13 |
