FEPSD-150 系列（工作压力 10 bar / 150 psi，爆破压力 40 bar / 600 psi）
| ITEM CODE | I.D | O.D mm | W.P | B.P | WEIGHT kg/m | MAX LENGTH m | |||
| mm | inch | bar | psi | bar | psi | ||||
| FEPSD019-150 | 19 | 3/4" | 32 | 10 | 150 | 40 | 600 | 0.83 | 40 |
| FEPSD025-150 | 25 | 1" | 38 | 10 | 150 | 40 | 600 | 1.02 | 40 |
| FEPSD032-150 | 32 | 1-1/4" | 45.5 | 10 | 150 | 40 | 600 | 1.31 | 40 |
| FEPSD038-150 | 38 | 1-1/2" | 52.2 | 10 | 150 | 40 | 600 | 1.63 | 40 |
| FEPSD051-150 | 51 | 2" | 65.2 | 10 | 150 | 40 | 600 | 2.11 | 40 |
| FEPSD064-150 | 64 | 2-1/2" | 79.2 | 10 | 150 | 40 | 600 | 2.75 | 40 |
| FEPSD076-150 | 76 | 3" | 91.2 | 10 | 150 | 40 | 600 | 3.22 | 40 |
| FEPSD102-150 | 102 | 4" | 120.4 | 10 | 150 | 40 | 600 | 5.48 | 40 |
FEPSD-230 系列（工作压力 16 bar / 230 psi，爆破压力 64 bar / 920 psi）
| ITEM CODE | I.D | O.D mm | W.P | B.P | WEIGHT kg/m | MAX LENGTH m | |||
| mm | inch | bar | psi | bar | psi | ||||
| FEPSD019-230 | 19 | 3/4" | 34 | 16 | 230 | 64 | 920 | 0.97 | 40 |
| FEPSD025-230 | 25 | 1" | 40 | 16 | 230 | 64 | 920 | 1.20 | 40 |
| FEPSD032-230 | 32 | 1-1/4" | 47.5 | 16 | 230 | 64 | 920 | 1.51 | 40 |
| FEPSD038-230 | 38 | 1-1/2" | 54.2 | 16 | 230 | 64 | 920 | 1.87 | 40 |
| FEPSD051-230 | 51 | 2" | 68 | 16 | 230 | 64 | 920 | 2.58 | 40 |
| FEPSD064-230 | 64 | 2-1/2" | 81.6 | 16 | 230 | 64 | 920 | 3.30 | 40 |
| FEPSD076-230 | 76 | 3" | 93.6 | 16 | 230 | 64 | 920 | 3.85 | 40 |
| FEPSD102-230 | 102 | 4" | 123.2 | 16 | 230 | 64 | 920 | 6.35 | 40 |
Note: Specifications, pressures, colors, etc. can be customized according to requirements.
